For Optical Engineer
Introduction
PanDao works as a cost and risk minimization software. It provides you with new tools for managing your projects.
As Optical Engineer, you are responsible for the Product Life Cycle (PLC) in your company. You ensure that your product development projects meet cost, quality and throughput requirements.
PanDao informs you throughout the whole life cycle of your product. It tells you about the needed fabrication technologies, the fabrication cost and the best fabrication chain to apply. That way, you are able to keep your target costs under control and meet your project's deadlines on time.
The only thing you need is access to a browser. PanDao runs on your PC or mobile phone.
Minimize fabrication risks
By applying PanDao you can minimize fabrication risk. To do that, it tells you the needed technologies and the optimum fabrication chain.
Besides, PanDao enables you to avoid too loose lens tolerancing levels. You can determine a stricter tolerancing for your lens without causing any more cost.
The following example shows the best fabrication chain for an aspherical lens. It has a diameter of 50 mm, made out of BK7 glass. It has shape accuracy 3/5(3), centering accuracy 4/5’, 3 nm RMS surface roughness and a Scratch/Dig level of 5/3*0.024.
For this asphere PanDao determines the following set of stricter tolerances. They can be applied without causing any increase of fabrication cost or risk.
With PanDao you can determine the process window of a fabrication chain where cost and risk stay constant. Without PanDao you don’t.
Reduce risk of project failing
Imagine, a critical design review is behind you. Your project is now in the implementation phase. You need to meet the deadline for delivering a set of prototypes to the customer now.
In this situation, you depend on stable prototyping manufacturing. The quality, throughput and cost goals have to meet on time.
PanDao supports you by determining the best fabrication chain at least cost or greatest speed for the prototyping batch.
The pictures below show the output of PanDao. The first picture is the most cost-efficient fabrication chain, the other the fastest.
The fastest fabrication chain for this lens is 2 times faster than the most cost-efficient. The disadvantage is that it causes 4.16 times more cost. The decision about the cost and speed is in your hand. Do you need a fast prototype or a cost optimized serial production?
PanDao will help you to decide without rely on suggestions from suppliers.
More Information
PanDao in action
If you want to see PanDao live, check out our introduction and tutorial videos on our channel.
Additional examples
For more examples how PanDao can be used, check out the following papers:
About the software
The development stage gives a comprehensive overview which products can be analyzed with PanDao. Check out our info flyer for even more information.
Licensing Models
Company-wide license
Purchase a package including a fixed number of PanDao requests. This package is not personalized and can be used company-wide and in parallel. →request quote!
Single user license
A single person subscribes to use PanDao. This single user license is personalized and not transferable to other users. It contains an unlimited number of requests. →request quote!
Design to fabrication service
Send us your optics lens’ specifications, and we will, NDA protected, analyze your design for optimal producibility at minimum fabrication cost. You can find additional information about our service here. →request quote!
Joint optics design and fabrication service
You take advantage of our Design to fabrication service in cooperation with www.JOYAteam.com and receive an optimized optical design that is focused on optimal producibility. →request quote!
Contact
Save money, deliver better design solutions and make your team happier.
Feel free to get in touch with us at any time: info@pandao.ch
